Part Status | Active |
|
Transistor Type | 2 NPN - Pre-Biased (Dual) |
|
Current - Collector (Ic) (Max) | 100mA |
|
Voltage - Collector Emitter Breakdown (Max) | 50V |
|
Resistor - Base (R1) | 4.7kOhms |
|
Resistor - Emitter Base (R2) | - |
|
DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 1mA, 5V |
|
Vce Saturation (Max) @ Ib, Ic | 150mV @ 250µA, 5mA |
|
Current - Collector Cutoff (Max) | 500nA (ICBO) |
|
Frequency - Transition | 250MHz |
|
Power - Max | 300mW |
|
Mounting Type | Surface Mount |
|
Package / Case | SC-74A, SOT-753 |
|
Supplier Device Package | SMT5 |
|
Base Product Number | FMG3AT148 |
|
