Category | Circuit Protection Transient Voltage Suppressors (TVS) TVS Diodes |
|
Mfr | Microchip Technology |
|
Series | Military, MIL-PRF-19500/516 |
|
Package |
|
|
Product Status | Active |
|
Type | Zener |
|
Bidirectional Channels | 1 |
|
Voltage - Reverse Standoff (Typ) | 136.8V |
|
Voltage - Breakdown (Min) | 171V |
|
Voltage - Clamping (Max) @ Ipp | 245.7V |
|
Current - Peak Pulse (10/1000µs) | 6.1A |
|
Power - Peak Pulse | 1500W (1.5kW) |
|
Power Line Protection | No |
|
Applications | General Purpose |
|
Capacitance @ Frequency | - |
|
Operating Temperature | -55°C ~ 175°C (TJ) |
|
Mounting Type | Surface Mount |
|
Package / Case | SQ-MELF, C |
|
Supplier Device Package | C, SQ-MELF |
|
Base Product Number | 1N6172 |
|
