Category | Circuit Protection Transient Voltage Suppressors (TVS) TVS Diodes |
|
Mfr | Microchip Technology |
|
Series | Military, MIL-PRF-19500 |
|
Package |
|
|
Product Status | Active |
|
Type | Zener |
|
Unidirectional Channels | 1 |
|
Voltage - Reverse Standoff (Typ) | 78V |
|
Voltage - Breakdown (Min) | 86.7V |
|
Voltage - Clamping (Max) @ Ipp | 126V |
|
Current - Peak Pulse (10/1000µs) | 22.8A |
|
Power - Peak Pulse | 3000W (3kW) |
|
Power Line Protection | No |
|
Applications | General Purpose |
|
Capacitance @ Frequency | - |
|
Operating Temperature | -65°C ~ 150°C (TJ) |
|
Mounting Type | Surface Mount |
|
Package / Case | DO-214AB, SMC |
|
Supplier Device Package | DO-214AB |
|
Base Product Number | SMLJ78 |
|
